Oxygen Concentrator AM-OC32 adopts 220V/110V AC power supply and use air as raw material and high-quality molecular sieve as adsorbent. It adopts the principle of pressure swing absorption (PSA) to directly separate oxygen from nitrogen at normal temperature and oxygen of high purity is there by produced. Concentrator helps improve the concentration of oxygen in the alveolar. It is light weight and has life span of more than 10000 hours. Uniform molecular packing density using automatic filling equipment. Maximum oxygen purity is up to 93%±3%. Seamless aluminum tube has higher tightness and longer service life.
Catalog
| Oxygen Flow | 5L/min |
|---|---|
| Oxygen Concentration | ≥93%±3 |
| Power Supply | 220V±22V 50Hz |
| Output Pressure | 20 Kpa to 60 Kpa |
| Input Power | 210VA |
| Sound Level | Less than 45 db |
| Net Weight | 25 Kg |
| Dimension | 500×320×240 mm |
| Working System | Continuous Flow |
| Atomization Quantity | >0.15ml/min |
It is widely used in hospitals and applied for middle aged and elderly, people with poor fitness, pregnant women, students and other people who suffer from different degrees of physiological hypoxia
Abimed portable oxygen concentrators are designed to provide supplemental oxygen for patients with breathing difficulties. These concentrators maintain an oxygen purity of 90% to 96% for effective treatment. They are smaller and lighter in weight which makes them easy to carry. These devices draw in oxygen using a battery, electricity, or DC power sources. Their portable design and compatibility with standard power supplies make them ideal for both home use and travel.
| Continuous Flow Settings | 0.5 to 2.0L |
| Pulse Flow Settings | 1 to 12 pulse settings equal to 0.5L to 8L |
| Oxygen Concentrator | 90% to 96% at any settings |
Abimed Stationary Oxygen Concentrators are designed for patients who need constant oxygen while they are at home or asleep. These concentrators maintain an oxygen purity between 90% and 96%. They are fully powered from a wall outlet, eliminating the need for batteries. The concentrators are equipped with wheels so they can be moved from one room to another with ease. Our stationary oxygen concentrators are ideal for long-term oxygen therapy.
| Flow Range | 2 to 10 Lpm |
| Maximum Flow | 10Lpm |
| Oxygen Purity | 93%±3% (2 to 9LPM), 90%±3% (10LPM) |
Abimed offers a range of high-quality medical oxygen concentrators designed to meet diverse patient needs. These concentrators provide adjustable flow rates, starting from 0.5 L/min up to 10 L/min, with oxygen purity consistently maintained at 90% or above. The units are energy-efficient, with power consumption ranging from 195 W to 300 W. They ensure minimal noise levels, creating a comfortable environment for patients. Our concentrators deliver reliable and consistent oxygen therapy, supporting patient health and wellness.
| Flow Rate | 10 L/min adjustable |
| Purity | 93%±3% |
| Power Supply | 220 V/50 Hz or 110 V/60 Hz |
| Flow Rate | 3 L/min adjustable |
| Purity | 93%±3% |
| Power Supply | 220 V/50 Hz or 110 V/60 Hz |
| Flow Rate | 5 L/min adjustable |
| Purity | 93%±3% |
| Power Supply | 220 V/50 Hz or 110 V/60 Hz |
| Flow Rate | 0.5 to 5 L/min adjustable |
| The Maximum Amount of Oxygen | 5 L/min≥90% |
| Power | 300 W |
