Medical Oxygen Concentrator AM-OC11

Medical Oxygen Concentrator AM-OC11 is a highly efficient low power consumption equipment in which oxygen is produced within 3 minutes when the power is on and its purity is high up to 93%±3%. It is designed with internal modules and an integrated system of oxygen modules for an easy and fast installation of the equipment. Likewise, it is connected by an alarm system, LED display, a monitor to check the oxygen purity, an alarm to indicate the power failure etc. are required to operate the equipment easily.

Catalog
Specifications
Flow Rate 0.5 to 3 L/min adjustable
The Maximum Amount of Oxygen 3 L/min≥90%
Power 195 W
Power Supply 220 V±22 V
Frequency 50 Hz±1 Hz
Input Power ≤300 VA
Noise ≤60 dB(A)
Transport & Storage Conditions Temperature: 20 to 55˚C Humidity: ≤93% Atmospheric Pressure: 50 kPa to 106 kPa
Life Time 8000 hours or 5 years
Oxygen Flow Rate & Concentration Flow rate: 0.5 to 3 L/minute Oxygen concentration: ≥90% (V/V)
Maximum Flow 3 L/minute
Electrical Classification Type 2 equipment Type B application part
Internal Dimension (L×W×H) 367×208×345 mm
External Dimension (L×W×H) 400×260×370 mm
Net Weight 8 Kg
Gross Weight 9.3 Kg
Features
Applications

Use air as raw material, use molecular sieve to transform pressure attach process to produce oxygen with a concentration range of 90% to 96%

Medical Oxygen Concentrators

Abimed offers a range of high-quality medical oxygen concentrators designed to meet diverse patient needs. These concentrators provide adjustable flow rates, starting from 0.5 L/min up to 10 L/min, with oxygen purity consistently maintained at 90% or above. The units are energy-efficient, with power consumption ranging from 195 W to 300 W. They ensure minimal noise levels, creating a comfortable environment for patients. Our concentrators deliver reliable and consistent oxygen therapy, supporting patient health and wellness.

Medical Oxygen Concentrator AM-OC12

Flow Rate 3 L/min adjustable
Purity 93%±3%
Power Supply 220 V/50 Hz or 110 V/60 Hz

Medical Oxygen Concentrator AM-OC13

Flow Rate 0.5 to 5 L/min adjustable
The Maximum Amount of Oxygen 5 L/min≥90%
Power 300 W
Medical Oxygen Concentrator AM-OC14
Flow Rate 5 L/min adjustable
Purity 93%±3%
Power Supply 220 V/50 Hz or 110 V/60 Hz
Medical Oxygen Concentrator AM-OC15
Flow Rate 10 L/min adjustable
Purity 93%±3%
Power Supply 220 V/50 Hz or 110 V/60 Hz

Abimed Stationary Oxygen Concentrators are designed for patients who need constant oxygen while they are at home or asleep. These concentrators maintain an oxygen purity between 90% and 96%. They are fully powered from a wall outlet, eliminating the need for batteries. The concentrators are equipped with wheels so they can be moved from one room to another with ease. Our stationary oxygen concentrators are ideal for long-term oxygen therapy.

Stationary Oxygen Concentrator AM-SOC33

Flow Range 2 to 10 Lpm
Maximum Flow 10Lpm
Oxygen Purity 93%±3% (2 to 9LPM), 90%±3% (10LPM)

Abimed portable oxygen concentrators are designed to provide supplemental oxygen for patients with breathing difficulties. These concentrators maintain an oxygen purity of 90% to 96% for effective treatment. They are smaller and lighter in weight which makes them easy to carry. These devices draw in oxygen using a battery, electricity, or DC power sources. Their portable design and compatibility with standard power supplies make them ideal for both home use and travel.

Portable Oxygen Concentrator AM-POC31
Continuous Flow Settings 0.5 to 2.0L
Pulse Flow Settings 1 to 12 pulse settings equal to 0.5L to 8L
Oxygen Concentrator 90% to 96% at any settings

Portable Oxygen Concentrator AM-OC32

Oxygen Flow 5L/min
Oxygen Concentration ≥93%±3
Power Supply 220V±22V 50Hz
